2.5kW 12V Hybrid Solar Inverter MPPT

A compact 2.5kW hybrid solar inverter for small homes, cabins and backup-power systems. It combines a 30–400V MPPT input, 12V battery operation, pure sine wave output and flexible grid or generator support in one wall-mounted unit.

2.5kW 12V Hybrid Solar Inverter MPPT

Available Models

Specification Model 1
DC Voltage 12V
Rated Power 2.5KW

Technical Specifications

Model 2.5KW-12V
AC Input
Rated Input Voltage (VAC) 208 / 220 / 230 / 240; L + N + PE
Voltage Range (VAC) 90–280 (APP/GEN Mode); 170–264 (UPS Mode)
Frequency (Hz) 50 / 60 (Auto Adaptive)
AC Output
Rated Capacity (kVA/kW) 2.5
Surge Power (kVA) 4
Voltage (VAC) 208 / 220 / 230 / 240
Power Factor (PF) 1
Frequency (Hz) 50 / 60
Switch Time (ms) 10 (APP/UPS Mode) / 20 (GEN Mode)
Waveform Pure Sine Wave
Overload Capacity
PV + Battery Mode / PV Mode 		Long-term @ 102%–125% Load;
10s @ 125%–250% Load
Max. Efficiency (Battery Mode) 91% @ 12VDC
Parallel Quantity N/A
Charger (PV / AC)
Solar Charger Type MPPT
Max. PV Input Current / Input Power 18A / 3000W
MPPT Range @ Operating Voltage (VDC) 30–400
Max. PV Open Circuit Voltage (VDC) 450
Max. PV Charge Current (A) 100
Max. AC Charge Current (A) 100
Max. Charge Current (PV + AC) (A) 100
Battery
Rated Voltage (VDC) 12
Max. Charging Current (A) 100
Max. Discharging Current (A) 150
Battery Type Lithium / Lead-acid
Interface
HMI LCD
Communication Interface RS485 / CAN / RS232 / CT (Optional) / Meter (Optional)
Monitoring WiFi (Optional / Built-in / External)
General Data
Ingress Protection IP21
Operating Temperature (°C) −10 to +60
Relative Humidity 5%–95% (Non-condensing)
Storage Temperature (°C) −15 to +60
Net Weight (kg) 4.5
Dimensions (W × H × D) (mm) 375 × 290 × 100
Max. Operating Altitude (m) 4000 (Derating Above 1000 m)

How It Works


Applications

Home Solar & Backup

Home Solar & Backup

Stable solar and backup power for essential household loads.

Remote & Off-Grid Sites

Remote & Off-Grid Sites

Practical power for cabins, farms and locations with limited utility access.

Small Commercial Projects

Small Commercial Projects

Flexible power support for shops, offices and light commercial loads.

System Matching & Wholesale Support


MOQ: Model-specific

Sample and bulk-order quantities are confirmed according to the selected model and project requirements.


OEM / ODM: Available

Custom branding, product configuration, manuals and packaging support for B2B orders.

Lead Time: Order-specific

Delivery schedule is confirmed after model, quantity and customization review.


Warranty: Model-specific

Warranty coverage follows the selected model and approved quotation.

Documents: On Request

Datasheets and available certification documents are provided on request.


Technical Support: Included

Pre-sales model selection and after-sales technical assistance.

Related Models

5kW 48V Parallel Type On/Off-grid Hybrid Solar Inverter 5kW 48V Parallel Type On/Off-grid Hybrid Solar InverterSingle-Phase Hybrid Inverters 4.2kW 24V Hybrid Solar Inverter MPPT with wide PV 500V | can work without battery 4.2kW 24V Hybrid Solar Inverter MPPT with wide PV 500V | can work without batterySingle-Phase Hybrid Inverters 12kW 48V Hybrid Solar Inverter MPPT with wide PV 500V | can work without battery 12kW 48V Hybrid Solar Inverter MPPT with wide PV 500V | can work without batterySingle-Phase Hybrid Inverters 2.5kW 12V Hybrid Solar Inverter with 100A MPPT 2.5kW 12V Hybrid Solar Inverter with 100A MPPTSingle-Phase Hybrid Inverters

FAQ

The correct model depends on load power, battery-bank voltage, surge demand and operating time. Send us your load list and system requirement for model selection.
