- Compatible for household appliances with AC 220V, DC 12V, and USB 5V output port.
- Plug & play design for simple installation
- Safety with full electrical protection
- LCD & LED display for system parameters and status
- Built-in pure sine wave inverter for wide-range of appliances, durable and stable
- Maximum solar generation with over 99% efficiency MPPT solar charge controller
- Available for gel, deep cycle, Lithium battery
| Model: |
SG1K |
SG2K |
SG3K |
| Rated Power |
1000W |
2000W |
3000W |
| Bat. Voltage |
24V |
24V |
24V |
| Inside Solar |
30A |
30A OR 60A |
30A OR 60A |
| Size(L*W*H) |
595*300*550mm |
605*550*525mm |
605*550*525mm |
| Packing Size(L*W*H) |
630*340*610mm |
650*600*590mm |
650*600*590mm |
| Battery size |
490*240*230mm |
490*500*230mm |
490*500*230mm |
| N.W.(kg) |
18KG |
28KG |
30KG |
| G.W.(kg) |
23KG |
35KG |
38KG |
| AC Input |
Voltage Range |
165VAC-265VAC |
| Frequency Range |
45Hz-65Hz |
| AC Output |
Voltage Range |
220Vac±5% |
| Frequency Range |
50Hz/60Hz±1% |
| Solar Controller |
controller type |
MPPT |
| Charging Current |
30A |
30A OR 60A |
30A OR 60A |
| PV Input Voltage Range |
12V System:26V-130V;
24V System:36V-130V;
48V System:65V-130V |
| Optimum voltage range |
12V System:30V-60V;
24V System:60-80V;
48V System:80V-120V |
| PV Array Max Power |
12V:360W/24V:750W;
24V System:750W/1440W;
48V System: 1440W/2800W |
| Output Wave |
Pure Sine Wave |
Total Harmonic
Distortion |
< 3%(Linear load) |
| Transfer Time |
<4ms |
| Efficiency |
≥85% |
| Working Mode |
Battery First |
When battery voltage ≤9.5V, switch to mains power |
| AC First |
mains first with AC charging |
| Saving energy mode |
Load power <10% , turns off, >11%-100% turns on |
AC Charging
Current |
5A/10A/20A/30A(Four gears available) |
| Battery Type |
Lead acid battery/lithium battery/LiFePo4 lithium battery |
| Display |
LCD+LED |
| Thermal method |
Cooling fan in intelligent control |
| Communication |
RS232 or WIFI (customization) |
| Protection |
Bat. low voltage alarm |
20.6V |
| Bat. low voltage Protection |
20V |
| Bat. over voltage Protection |
33V |
| Bat. overvoltage alarm |
32V |
| Over Power Protection |
120% more than rated capacity |
| Temperature Protection |
>85*C alarm, >90*0 machine shut off |
| AC Output short circuit |
YES |
| Environment |
Noise |
≤55dB |
| Temperature |
-10°C-40°C |
| Humidity |
0%-95% (No condensation) |
| DC output |
5VDC USB output port |
2pcs/max 2A |
| 12VDC output port |
2pcs/max4A |
| Battery space |
595*300*550mm
(24V 100AH) |
490*600*230mm
(24V 200AH) |
FAQ
Q1: Can I have a sample/trial order for a test?
A: Yes, we accept sample order/trial order for you testing by 1 product or mixed solar products.
Q2: When will you deliver the goods?
A: 3-5 working days for sample order; 7-15 working days for quantity order after receiving the deposit payment.
Q3: Do you offer a guarantee for your solar products?
A: Yes, 18 months for inverter and inverter-related products including solar generator, solar inverter. 2 years for solar lights.
Q4: Can you do OEM/ODM?
A: Yes, we accept OEM/ODM orders for inverter, solar inverter, MPPT solar controllers, solar generator and solar lights.
Please send you detailed request to our sales specialist for best quote.
